Development of Logic Circuits with Diamond-Based Transistors

—A Step Forward in the Development of Diamond-Based Integrated Circuits Operational under Extreme Environments—

National Institute for Materials Science(NIMS)

A NIMS research group has succeeded for the first time in the world in developing a logic circuit equipped with diamond-based MOSFETs (metal-oxide-semiconductor field-effect-transistors) at two different operation modes. This achievement is a first step toward the development of diamond integrated circuits operational under extreme environments.

(“Logic Circuits With Hydrogenated Diamond Field-Effect Transistors”; Jiangwei Liu, Hirotaka Ohsato, Meiyong Liao, Masataka Imura, Eiichiro Watanabe, Yasuo Koide ; IEEE Electron Device Letters ( Volume: 38, Issue: 7, July 2017 ) ; DOI: 10.1109/LED.2017.2702744)

Abstract

  1. A NIMS research group led by Jiangwei Liu (independent scientist, Research Center for Functional Materials) and Yasuo Koide (coordinating director in the Research Network and Facility Services Division) has succeeded for the first time in the world in developing logic circuits equipped with diamond-based MOSFETs (metal-oxide-semiconductor field-effect-transistors) at two different operation modes. This achievement is a first step toward the development of diamond integrated circuits operational under extreme environments.
  2. Diamond has high carrier mobility, a high breakdown electric field and high thermal conductivity. Therefore, it is a promising material to be used in the development of current switches and integrated circuits that are required to operate stably at high-temperature, high-frequency, and high-power. However, it had been difficult to enable diamond-based MOSFETs to control the polarity of the threshold voltage, and to fabricate MOSFETs of two different modes—a depletion mode (D mode) and an enhancement mode (E mode)—on the same substrate. The research group has successfully developed a logic circuit equipped with both D- and E-mode diamond MOSFETs after making a breakthrough by fabricating them on the same substrate using a threshold control technique developed by the group.
  3. The research group identified the electronic structure in the interface between various oxides and hydrogenated diamond using photoelectron spectroscopy in 2012. The research group then succeeded in developing a diamond MOS (metal-oxide-semiconductor) capacitor with very low leakage current density and an E-mode hydrogenated diamond-based MOSFET in 2013 after going through many difficulties. The group then prototyped logic circuits by combining diamond-based MOSFETs with load resistors in 2014. Finally, the group developed techniques to control D- and E-mode characteristics of diamond-based MOSFETs and identified the control mechanism in 2015. A series of these R&D accomplishments were introduced in AIP publishing news by the American Institute of Physics. These previous efforts led to the success made in this research project.
  4. The logic circuits with diamond-based transistors are promising devices to be used in the development of digital integrated circuits that are required to stably operate under extreme environments such as high-temperature as well as exposure to radiation and cosmic rays.
  5. This research was conducted in conjunction with the following projects: Leading Initiative for Excellent Young Researchers (Jiangwei Liu, representative), under the sponsorship of the MEXT Human Resource Development Program for Science and Technology; “Development of new functional diamond electronic devices using a large amount of polarized charges” (Yasuo Koide, principal investigator), under the category of Grant-in-Aid for Scientific Research (A) sponsored by the MEXT Grants-in-Aid for Scientific Research; and “Fabrication of high-current output fin-type diamond field-effect transistors” (Jiangwei Liu, principal investigator), under the category of Grant-in-Aid for Young Scientists (B) sponsored by the MEXT Grants-in-Aid for Scientific Research. Device fabrication was supported by the NIMS Nanofabrication Platform, established under the MEXT Nanotechnology Platform Japan program.
  6. The preprint of this study was published on May 9, 2017, local time, in the online version of IEEE Electron Device Letters (sponsored by the IEEE Electron Devices Society based in the US) available at the IEEE Electron Digital Library website.

"Figure: Micrograph of a fabricated logic circuit equipped with diamond-based transistors" Image

Figure: Micrograph of a fabricated logic circuit equipped with diamond-based transistors
