施設・装置
NMRシステム
[1] 800 MHz固体高分解能NMRシステム(WB)
800 MHz widebore solid-state NMR system
JNM-ECZ800R (JEOL/JASTEC)
- 18.79 T (1H: 800 MHz) / φ89
-
Probes:
HX (1 mmφ/70 kHz, 2 mmφ/40 kHz, 3.2 mmφ/22 kHz),Cryocoil (Optional) - CP/MAS, MQMAS etc.
[2] 800 MHz 固体高分解能NMRシステム(NB)
800 MHz narrowbore solid-state NMR system
JNM-ECZ800R (JEOL/JASTEC)
- 18.79 T (1H: 800 MHz) / φ54
-
Probes:
HX (1 mmφ/70 kHz, 3.2 mmφ/22 kHz) - CP/MAS, MQMAS, Low γ-MAS
[3] 500 MHz 固体高分解能NMRシステム
500 MHz wide-bore solid-state NMR system
JNM-ECZ500R (JEOL/JASTEC)
- 11.75 T (1H: 500 MHz) / φ89
- Variable temperature unit (-150 ℃ ～ +250 ℃)
-
Probes:
HX (3.2 mmφ/22 kHz, 4 mmφ/15 kHz)
HX (4 mmφ/15 kHz with a Low-γ kit, Phoenix)
HXY (4 mmφ/15 kHz)
Static (6 mmφ, with an optional goniometer, Doty) - CP/MAS, MQMAS, Static (anisotropy)
- Remote Operation through WebEX system
[4] 500 MHz 固体汎用NMRシステム
500 MHz multi-purpose NMR system
JNM-ECZ500R (JEOL/Oxford Instruments)
- 11.75 T (1H: 500 MHz) / φ89
-
Probes:
HX (3.2 mmφ/22 kHz, 4 mmφ/15 kHz)
HX (4 mmφ/15 kHz with a Low-γ kit, Phoenix)
HXY (4 mmφ/15 kHz)
Static (home-built, with a He gas-flow cryostat)
- CP/MAS, Static (broad line at cryotemperatures), etc.
独自開発装置
[1] 高温用パルス磁場勾配プローブ
High-temperature pulsed field gradient probe
-
Measures diffusion coefficients in ion battery materials at high temperatures.
- Operates effectively up to 700 K.
[2] 半導体超偏極用光ポンピングNMR装置
Optical pumping NMR system for semiconductors
- Builds up nuclear hyperpolarization in semiconductors at cryogenic temperatures.
- Equipped with double resonance capability.
- Used for NMR quantum information processing.
